Complete Service Body Filter Regulator Lubricator

052141

Awaiting stock, shipping soon
$392.14
$392.14
Shipping calculated at checkout.
  • Fully secure checkout
  • Trusted by thousands
  • Decades of Experience

Protect your air-powered equipment investment with comprehensive air treatment and conditioning.

Maintain peak performance and extend the service life of pneumatic tools with a Complete Service Body Filter Regulator Lubricator. This modular FRL system treats compressed air before it reaches your tools—the filter removes water, dirt, and oil contaminants; the regulator controls pressure from the compressor; and the lubricator delivers oil downstream to reduce wear and improve performance.

Specifications

Configuration

Filter, Regulator, Lubricator (3-in-1 System)

Dimensions (LxWxH)

5 in x 6.18 in x 10.6 in

Weight

3.5 lb

Product Specs
  • Inlet Size: ½” NPT
  • Outlet Size: ½” NPT
  • Components: Filter, Regulator, Lubricator (3-in-1 System)
  • Mounting: (2x) 1/4" BOLTS 3.25” vertically spaced
  • Pressure Range: 250psi - REGULATED PRESSURE 0-150PSI
  • Maximum Flow Rate: 120CFM
  • Filter Rating: 40 µm
  • Lubricator Bowl Capacity: 3.5oz / .1L

Materials
  • Aluminum

WHAT'S IN THE BOX

  • Complete Filter Regulator Unit
  • Mounting Bracket
  • Drain Valve (if applicable)
  • Install Hardware

Warranty

Not Applicable
